2. Wideband Devices
These are not recommended for new designs. For alternatives, see the Si533x family of products.
2.1. Narrowband vs. Wideband Overview
The narrowband (NB) devices offer a number of features and capabilities that are not available with the wideband
(WB) devices, as outlined in the below list:
 Broader set of frequency plans due to more divisor options
 Hitless switching between input clocks
 Lower minimum input clock frequency
 Lower loop bandwidth
 Digital Hold (reference-based holdover instead of VCO freeze)
 FRAMESYNC realignment
 CLAT and FLAT (input to output skew adjust)
 INC and DEC pins
 PLL Loss of Lock status indicator
 FOS is not supported.
Table 2. Product Selection Guide (Si5322/25/65/67)
Device Clo
ck Input
s
Clo
ck Ou
tpu
ts
P Control
Ma
x In
put Fr
eq (M
Hz)
*
Ma
x Out
put
F
requ
e
nc
y (MHz)
Jit
ter
Gene
rat
io
n
(1
2
k
Hz – 20
M
H
z)
LOS Hit
less
Swit
ching
FOS Alarm LOL Alarm FSYNC Rea
lignme
n
t
36
L
ead
6
mm
x
6
mm QFN
10
0 Lea
d 14 x 1
4
mm TQFP
1.8, 2.5, 3.3 V
Opera
tion
1.8, 2.5 V
Oper
at
ion
Low Jitter Precision Clock Multipliers (Wideband)
Si5322 2 2 707 1050 0.6 ps rms typ
  
Si5325 2 2

710 1400 0.6 ps rms typ
   
Si5365 4 5 707 1050 0.6 ps rms typ
   
Si5367 4 5

710 1400 0.6 ps rms typ
   
*Note: Maximum input and output rates may be limited by speed rating of device. See each device’s data sheet for ordering
information.
