S i 5 3 x x - R M
108 Rev. 1.2
A
PPENDIX
A—N
ARROWBAND
R
EFERENCES
Resonator/External Clock Selection
The following is a list of tested and approved, third-overtone 114.285 MHZ crystals. All are in a small form factor
3.2 x 2.5 mm SMD package. See “AN591: Crystal Selection for the Si5315, Si5327, and other Si53xx Any-
Frequency Jitter Attenuating Clocks” for additional information on crystals.
The ultra-low loop BW of the Si5328 typically requires that it use an external TCXO/OCXO instead of a crystal.
See “AN775: Si5328 / ITU-T G.8262Y.1362 EEC Options 1 and 2 Compliance Test Report” and “AN776: Using the
Si5328 in ITU G.8262-Compliant Synchronous Ethernet Applications” for more details.
Table 50. Approved 114.285 MHz Crystals
Manufacturer Part Number Website Stability Initial
Accuracy
Abracon ABM8–114.285 MHz–D2X–T http://www.abracon.com 20 ppm 20 ppm
Connor Winfield CS-023E http://www.conwin.com 20 ppm 20 ppm
Hosonic E3SB114.285T00M33 http://www.hosonic.com 30 ppm 30 ppm
Mtron M1253S071 http://www.mtronpti.com 100 ppm 100 ppm
NDK EXS00A-CS00871 http://www.ndk.com/en/ 100 ppm 100 ppm
NDK EXS00A-CS00997 http://www.ndk.com/en/ 20 ppm 20 ppm
Pericom
(Saronix/eCera)
FLB420001 http://www.pericom.com/saronix
http://www.ecera.tw
100 ppm 100 ppm
Pericom
(Saronix/eCera)
FLB420004 http://www.pericom.com/saronix
http://www.ecera.tw
20 ppm 20 ppm
Siward XTL573200NLG-114.285 MHz-OR http://www.siward.com 20 ppm 20 ppm
TXC 7MA1400014 http://www.txc.com.tw 100 ppm 100 ppm
Vectron VXM7-1074-114M285000 http://www.vectron.com 100 ppm 100 ppm
Note: Silicon Labs has confirmed that the listed crystals meet internal specifications for the XA/XB interface. These crystals
have been tested for functional and performance compatibility for use with the Si53xx. For crystal technical support
questions, please contact the crystal supplier.
