Sennheiser Set 820 - Manual (Page 41)

41
English
Technical data
Modulation FM, stereo
Carrier frequencies see type plate at the base of the transmitter
AF frequency response 40 Hz ....... 15 kHz
S/N ratio 60 dB A rms
Transmitter
RF output power
typ. up to 10 mV
Audio input 3.5 mm jack, stereo/mono
Microphone socket 2.5 mm jack, mono
Charging time for battery approx. 4 h
Charging time (spare battery) approx. 10-12 h
Power supply 12 V DC via NT 820 mains unit
Weight approx. 94 g (without battery)
Dimensions diameter: 3.8 inch, heigth: 1.1 inch
Receiver
Max. sound pressure level
> 125 dB
Power supply 2.4 V via BA 151 battery
Operating time more than 4 hours per battery
Weight approx. 60 g (without battery)
Dimensions length: 9.0 inch, width: 4.9 inch, heigth: 1.0 inch
