Product overview
Product overview
Overview of the EK 100 G3 diversity receiver
³ 3.5 mm jack socket ( LINE ), lockable
(the ground contact is used by antenna II)
· Antenna I
» Operation and battery status indicator, red LED
lit = ON
flashing = LOW BATT
¿ RF signal indication, green LED
lit = RF
´ Charging contacts
² SET button
¶ ̆
/
̄
rocker button ( UP / DOWN )
º Battery compartment
¾ Battery compartment cover
µ Battery compartment catches
¸ Infra-red interface
¹ ON
/ OFF button with ESC function (cancel)
Ƹ Display panel, backlit in orange
·
»
¿
²
´
¹
¸
´
Ƹ
º
¾
µ
µ
³
¶
