8
Putting the diversity receiver into operation
̈
Lift one side of the belt clip Ƽ as shown.
̈
Press down the belt clip Ƽ at one fixing point and pull it out of the
receiver housing.
̈
Repeat for the other side.
̈
Place the perforated plate ƹ onto the rear of the receiver.
̈
Reinsert the belt clip Ƽ .
̈
Use one of the supplied line cables to connect the line input of the
camera to the socket
³ .
The ground connection of the line cable serves as the antenna for
the second diversity section. For details on the connector assign-
ment, refer to the diagram on page 24.
Ƽ
³
