110 www.seuservice.com
23 CLUTCH UNIT (FRI-2400) ( D-2/2 )
ITEM NO. PART NO. DESCRIPTION NOTE
1 FRI-2401 BOTTOM COVER
2 FRI-2402 CLUTCH SPRING A
3 FRI-2403 CLUTCH GEAR
4 FRI-2404 CLUTCH BASE
5 FRI-2405 SPRING STOPPER
6 FRI-2406 CLUTCH PEDAL
7 FRI-2407 CLUTCH SPRING B
8 FRI-2408 STOPPER BASE
9 FRI-2409 BEARING PLATE
10 FRI-2410 VR BRKT
11 FRI-2411 SPRING HOLD
12 FRI-2412 CLUTCH RUBBER B
13 FRI-2413 CLUTCH RUBBER A
14 FRI-2414 CLUTCH COLLAR
15 FRI-2415 INSULATOR
16 FRI-2416 NON SLIP SHEET
17 FRI-2417 STOPPER COLLAR
101 100-5359 BEARING 16
102 220-5484 VOL CONT B-5K OHM
220-5373 VOL CONT B-5K OHM
103 601-7944 GEAR 15
104 310-5029-F15 SUMITUBE F F 15MM
105 280-0419 HARNESS LUG
106 280-5275-SR10 CORD CLAMP SR10
201 028-A00304-P SET SCR HEX SKT CUP P M3 X 4
202 000-P00308-W M SCR PH W/FS M3 X 8
203 000-T00406-0B M SCR TH BLK M4 X 6
204 000-P00408-W M SCR PH W/FS M4 X 8
205 000-P00410-W M SCR PH W/FS M4 X 10
206 000-P00416-W M SCR PH W/FS M4 X 16
207 FAS 000062 M SCR TH CRM M6 X 8
301 FRI-60093 WIRE HARN CLUTCH
