Soleus Air SOLEUSAIR SG-TTW-09ESE-26 - Manual (Page 3)

Specifications
• Noise level is measured at a distance of 3.28ft away from the front of the unit in cooling mode.
• Power consumption is measured when the fan runs at the highest speed settings.
• These specifications are for reference only. For actual data, please refer to the rating label on the unit.
Model Number SG-TTW-09ESE-26 SG-TTW-09HC-26 SG-TTW-12ESEZ-26 SG-TTW-12HC-26
Power Supply (Ph/V/Hz) 1/115/60 1/230-208/60 1/115/60 1/230-208/60
Dehumidifying Capacity (Pt/Day) 60 60 81.6 81.6
Rated Cooling Capacity (BTU/Hr) 9,200 9,200/8,900 11,800 11,800/11,400
Rated heating Capacity (BTU/Hr) N/A 11,000/9,000 N/A 11,000/9,000
Cooing Power Input (Watt) 940 940/910 1,260 1,200/1,160
Heating Power Input (Watt) N/A 3,500/2,900 N/A 3,500/2,900
Rated Current Cooing (Amperage) 8.6 4.4/4.7 11.6 5.6/6.0
Rated Current Heating (Amperage) N/A 15/14 N/A 15/14
EER 9.8 9.8 9.4 9.8
Air Flow (CFM) 283/259/236 271/247/224 283/259/236 271/247/224
Noise Level Indoor/Outdoor [dB(A)] 56/64 56/64 56/64 56/64
Product Dimensions WxDxH (Inch) 26" x 21.125" x 15.625" 26" x 21.125" x 15.625" 26" x 21.125" x 15.625" 26" x 21.125" x 15.625"
Product Weight (Lb) 75 77 77 79
Refrigerant R-410A R-410A R-410A R-410A
Energy Star Yes No Yes No
