DeviceNet Communication Adapter
3
1.2
Specifications
Table 1 General Specifications
Description Specification
ODVA compliance Complies with ODVA Specification Release 2.0 for group 2
only slave supporting polled and strobed connections.
Data rate Supports 125/250/500 Kbaud standard DeviceNet rates.
Network power loading Voltage: Operational from 11 ... 25 Vdc.
Current drain: 110 mA maximum, 75 mA typical.
Required enclosure Adapter is considered open equipment, requires enclosure
according to application.
Environment, RFI, EMI Adapter conforms to the specification for the I/O base upon
which it is mounted. See the Momentum I/O Bases User
Manual, 870 USE 002 00 for I/O base specifications.
Agency approval ODVA Certification
UL 508, 746C, 94
CSA 22.2 No. 142
CE Mark
FM Class 1 Div 2 Groups A, B, C, D
Table 2 Environmental Specifications
Description Reference Specification
Temperature, Operating IEC 68–2–14 0 ... 60 _ C ambient
Temperatore, Storage IEC 68–2–14 –40 ... 85 _ C
Humidity IEC 68–2–3 95% RH at 60 _ C non–condensing
Altitude MIL–STD–810 15 000 ft
Vibration, Operating IEC 68–2–6 10 ... 57 Hz: 0.075 mm DA
57 ... 150 Hz: 1 g
Shock, Operating IEC 68–2–27 15 g, 11 ms, 3 shocks/axis
Free Fall, Unpackaged IEC 68–2–32 0.1 m
Free Fall, Packaged IEC 68–2–32 24 in
