A-2
Dip Switch Setting
* With a RS-485 serial interface specification (a dealer option), DIP
switches 2-7 and 2-8 are ignored.
Notes:
•
Changes in DIP switch settings (excluding switches 2-7 and 2-8 interface reset
signals) are recognized only when the printer power is turned on or when the
printer is reset by using the interface. If the DIP switch setting is changed after
the printer power is turned on, the change does not take effect until the
printer is turned on again or is reset.
•
If you turn on DIP switch 2-7 or 2-8 while the printer is turned on, the printer may
be reset, depending on the signal state. DIP switches should not be changed
while the printer power is on.
Transmission Speed
Transmission Speed (BPS)-bits per second
1-7
1-8
2400
ON
ON
4800
OFF
ON
9600
ON
OFF
19200
OFF
OFF
Set 2
SW
Function
ON
OFF
2-1
Handshaking (BUSY
condition)
Receive buffer full
Off line or
receive buffer full
2-2
Customer display
(DM-D) connection
Connected
Not connected
2-3~
2-4
Undefined
—
2.5~
2.6
Internal use
Fixed to Off
2-7*
I/F pin 6 reset signal
Enabled
Disabled
2-8*
I/F pin 25 reset signal
Enabled
Disabled
