Smooth Fitness V2300 User Manual
Page 26
26
“
P
ART
L
IST
”
NO.
Item Name
Q'TY
1
Main Frame
1
2
Rear Support Frame
1
3
Rail Pivot
1
4
Outer Seat Support Slider
1
5
Inner Seat Support Slider
1
6
Handlebar (L&R)
2
7
Front Stabilizer
1
8
Rear Stabilizer
1
9
Seat Carriage
1
10 Seat Frame
1
11 Seat Handlebar
1
12 Left Pivoting Arm
1
13 Right Pivoting Arm
1
14 Pedal Support Arm (L&R)
2
15 Left Pedal Slider
1
16 Right Pedal Slider
1
17 Rotation Stand
2
18 Left Pedal Linkage
1
19 Right Pedal Linkage
1
20 Pedal Arm Connector
4
21 Crank Cover (L&R)
2
22 Left Chain Cover
1
23 Right Chain Cover
1
24
Decoration Cover for Carriage
Slider
1
25 Left Rear Chain Cover
1
26 Right Rear Chain Cover
1
27 Connection Cover
1
28 Top Front Decoration Cover
1
29 Top Rear Decoration Cover
1
30 Long Timing Belt
1
31 V-Ribbed Belt for Pulley
1
32 Pulley
1
33 Magnet
1
NO.
Item Name
Q'TY
34 Bearing Housing
4
35 Transportation Wheel (L&R)
2
36 Round EndCap
2
37 Adjusting Rear Stabilizer EndCap
2
38 leveler
1
39 Bushing (60x10mm)
4
40 Slider Sleeve
1
41 Left Rail Decoration Cover
1
42 Right Rail Decoration Cover
1
43 Rail Connection Cap
1
44 Square Stopper
4
45 Console Upper Cover
1
46 Console Bottom Cover
1
47 Round Plug
2
48 Handlebar Foam Grip (L&R)
2
49 Idler Wheel
1
50 Left Seat Carriage Cover
1
51 Right Seat Carriage Cover
1
52 Seat Fixed Wheel
1
53 Roller (37.7mm)
4
54 Square Plug (25x75mm)
1
55 Adjusting Handle
1
56 Seat
1
57 Back Cushion
1
58 Screw Cap
2
59 Round Plug (25.4mm)
4
60 Square Plug (20x40mm)
1
61 Button Plug (31.8mm)
2
62 Hand Pulse Sensor (L&R)
2
63 Seat Handlebar Foam Grip (L&R)
2
64 Pivoting Arm Pushing (A)
2
65 Pivoting Arm Pushing (B)
2
66 Bushing Cap
2
