Shark SSG-503537E/G - Manual (Page 22)

SHARK SSG • 8.914-337.0 / 97-6134 • Rev. 8/07
OPERA
TOR’S MANU
AL
PRESSURE
W
ASHER
ExPLODED vIEW PARTS LIST
ITEM PART NO. DESCRIPTION qTy
1 95-0700055 Coil, Rodless 1
95-0700010 Top Wrap, SS 1
-01104 ▲ Trim 6 ft.
3 7-01484 Insulation/Blanket,
Die Cut 8" x 4" 1
4 7-01430 Insulation/Blanket,
No Foil, 4" x 57" 1
5 7-0140 Insulation, Burner Head
No Hole 1
6 95-070001 Weldment, Bottom Wrap, SS 1
90-1019 ▲ Bolt, 3/8" - 16 x 1-3/4"
7 7-0141 Insulation, Burner Head,
w/Hole 1
8 90-19959 Screw, 3/8" x 1" HX Wash Head,
Sheet Metal 8
9 7-0144 Gasket, Burner Plate
10 95-0711113 Insulation Retainer Plate
90-990 ▲ Screw, SS #10, HH Tek 8
11 -010066 Elbow, Zinc 1
1 -00101 Nipple, 1/" x 4" Galv.
Sch 80 1
13 4-0047748 Hose 3/8" x 48", Wire
Pressure 1
14 -010061 Bushing, Rubber 3
15 -1019 Elbow 3/8" Female 1
16 -3409 Disk Rupture Assy, 7000 PSI 1
17 95-071016 Block, Discharge, Brass,
1/" x 1/" 1
18 -00681 Bushing, 1/" x 3/8"
19 -007 Nipple, 3/8" x 3/8" NPT ST
Male 1
0 -1108 Hose Barb, 1/" Barb x 3/8"
MPT, Push-On 1
1 4-0110000 Hose, 1/" Push-On ft.
-010065 Diptube, Plastic, 10.00" Long
(5030, 5035, 6035) 1
3 -99050 Filter, Fuel Oil/H O Separator 1
4 -0054 Elbow, 1/" MNPT x 1/" MJIC,
Steel 1
5 -9040 Clamp, Hose, UNI .46 - .54 6
6 -1085 Hose Barb, 1/4" Barb x
1/4" Pipe 1
7 90-30010 Screw, #14 Tek, Black, Zinc 11
8 Pump, See Specifications Pages 30-31
9 5-308 Unloader AL607 1
30 6-0170 Pressure Switch 1
ITEM PART NO. DESCRIPTION qTy
31 -300816 Pump Protector, 3/8" FNPT 1
3 4-0047716 Pressure Hose 3/8" x 16" 1
33 4-0110000 Hose 1/" Push On 17 in
34 4-0110000 Hose, 1/" Push On ft.
35 -1105 Push On JIC, 1/" 4
36 95-07101150/B Block, Unloader, 1/" x 1/",
Brass 1
37 95-0700054 Rail, Pump 1
-011981 ▲ Washer, Snubbing 3
90-1016 ▲ Bolt, 3/8 x 1" NC HH 3
90-4009 ▲ Washer, 3/8" Lock Split
Ring 3
38 -1041 Tee, 1/", w/1/8" Hole, Street 1
-104 Tee, 1/", w/1/8" Hole, Street
(Steam Option) 1
39 70-460146 Cap, Valve, Shark Pump,
w/Steam Option 1
40 -106 Elbow, 1/" JIC x 1/", 90° 1
41 -1060 Elbow, 1/" x 3/8, 90° 1
4 -0053 Elbow, 1/" MJIC x 3/8"
MNPT 1
43 -0051 Nipple, 1/" MJIC x 3/8"
MNPT 1
44 -0079 Swivel, 1/" JIC Fem, 3/8"
Male 1
45 -005 Nipple, 1/" JIC, 1/" Pipe 1
46 -1050 Plug, 1/" Flare
(5030, 5035, 6035) 1
47 95-0700015 Heat Shield (Honda)
(5035, 6035) 1
95-0700048 ▲ Heat Shield (Vanguard) 1
90-1995 ▲ Screw, M6 x 0mm, BH
(Honda) (5035, 6035) 4
48 77-VHRM4 Muffler (Honda) (5035, 6035) 1
79-11465813800 Exhaust Deflector (Honda)
(5035, 6035) 1
76-807965 ▲ Muffler (Vanguard) 1
90-805849 ▲ Screw, HH, 1/4" - 0 x 1/"
(Vanguard) 4
48 90-19711 ▲ Screw, HH, WL, 1/4" -
0 x 1/" (Vanguard) 5
95 -07101149 ▲ Muffler Guard (Vanguard) 1
95-071011491 ▲ Brace (Vanguard)
95-0700048 ▲ Shield, Heat (Vanguard) 1
90-0001 ▲ Nut, 1/4 Flange, Zinc
(Vanguard) 3
90-031 ▲ Nut, Cage, 1/4 x 1 Ga.
(Vanguard)
