Q. Electronic Shutter/Auto Iris
Selector Switch: On/off switchable
R. Reduce Noise: Low, Middle, High, Off selectable
S. Sharpness: On/Off (level adjustable)
T. Privacy Function: On/Off (4 programmable zones)
U. Motion Detection: On/Off (4 programmable zones)
V. D/N Color: Always color/day-night operation
W. Signal Processing: Digital signal processing (DSP)
X. Gamma Correction: 0.45
Y. Video Output: 1 Vp-p, 75 ohms
Z. Signal-to-Noise Ratio: >50 dB
AA. Minimum Illumination 0.002 Lux (Intensifier™) / 0.03 Lux (shutter)
BB. Synchronization System: Internal/ line lock selectable through OSD
CC. Housing Tamper resistant aluminum composite/polycarbonate.
IP67 water resistant/weatherproof
2.04 ELECTRICAL SPECIFICATIONS
A. Input Voltage: 10-15V DC, 22-28V AC
B. Power Consumption: 230mA (DC)/3.8 (AC) maximum
C. Video Connector: BNC
D. Lens Jack: Built-in
F. Video Test Connector Proprietary cable harness with BNC connector
G. Power Supply 12V DC & 24A VC (dual voltage) required
2.05 ENVIRONMENTAL SPECIFICATIONS
A. Operating Temperature: -20° to 122°F (-29° to +50°C)
B. Storage Temperature: -30° to 140°F (-34° to +60°C)
C. Operating Humidity: up to 95%, noncondensing
D. Storage Humidity: up to 95%, noncondensing
2.06 PHYSICAL SPECIFICATIONS
A. Dimensions: 6.29” Diameter x 3.89” H (12.7 cm x 9 cm)
B. Weight: 1.75 lbs. (0.68 kg)
2.07 MECHANICAL SPECIFICATIONS
A. Lens Mount: Varifocal proprietary board type
B. Camera Mount: Wall and ceiling with internal 3-axis mount
2.08 WARRANTY
A. 5 years, parts and labor
2.09 SPECO TECHNOLOGIES MODEL NUMBERS
A. HT728FFiL: 2.8 to 10mm Focus Free auto iris motorized zoom lens, 10-15V DC or
22-28V AC, grey base with paintable Chameleon™ cover
Works in conjunction with these available accessories:
B. RCINT: IR remote control for HT7248FFiL
C. CVCTPEXT: Adapts HT7248FFiL to accept conduit, also acts as a junction box
D. CVCTPLATE: Bullet Camera mounting accessory for junction box/conduit access point
E. 7246WMT: Wall Mount
