3. INTERFACE SPECIFICATIONS
The table below shows the commands supported by the digital video recorder.
DVR/VCR command table
Left digit
Right digit
0 1 2 3 4 5 6 7
0
TIMER
ON/OFF
1
2
AUDIO
3 SHIFT SHIFT
4 SHIFT SHIFT MENU
5
SHIFT+
/RP UP
6
SHIFT-
/RP DOWN
7
8
9
SECURITY
LOCK ON
A PLAY
REV PLAY
/SEARCH
(DVR)
SECURITY
LOCK OFF
B
C
GROUP SET
D
GROUP
CHECK
E
GROUP
CLEAR
F STOP STILL
Left digit
Right digit
8 9 A B C D E F
0 CAMERA 1
CLOCK
ADJUST
1 CAMERA 2
MENU
RESET
2 CAMERA 3
3 QUAD CAMERA 4
4
5
6
7 SEQUENCE
STATUS
SENSE
8
9
CLOCK
DOWNLOAD
A REC
REC/DUB
REQUEST
B FF
C REW
D
E
OSD/EXIT
F
STATUS
LOG1
REC STOP
