Page 56
56
CDX-CA850/CA850X/CA860X
Ref. No.
Part No.
Description
Remark
Ref. No.
Part No.
Description
Remark
MAIN
Q310
8-729-920-21 TRANSISTOR DTC314TKH04
Q401
8-729-021-82 TRANSISTOR 2SD2396K
Q402
8-729-421-22 TRANSISTOR UN2211
Q403
8-729-424-08 TRANSISTOR UN2111
Q405
8-729-421-22 TRANSISTOR UN2211
Q406
8-729-920-85 TRANSISTOR 2SD1664-QR
Q407
8-729-424-08 TRANSISTOR UN2111-TX
Q501
8-729-040-17 TRANSISTOR 2SD2164-K
Q602
8-729-421-22 TRANSISTOR UN2211
Q603
8-729-424-18 TRANSISTOR UN2113
Q701
8-729-424-08 TRANSISTOR UN2111
Q702
8-729-106-60 TRANSISTOR 2SB1115A-YQ
Q703
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q705
8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q706
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q801
8-729-024-95 TRANSISTOR 2SB1565EF
Q802
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q803
8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101
1-216-821-11 METAL CHIP
1K
5%
1/16W
R102
1-216-073-00 METAL CHIP
10K
5%
1/10W
R103
1-216-073-00 METAL CHIP
10K
5%
1/10W
R104
1-216-821-11 METAL CHIP
1K
5%
1/16W
R105
1-216-841-11 METAL CHIP
47K
5%
1/16W
R106
1-216-829-11 METAL CHIP
4.7K
5%
1/16W
R107
1-216-841-11 METAL CHIP
47K
5%
1/16W
R108
1-216-829-11 METAL CHIP
4.7K
5%
1/16W
R109
1-216-829-11 METAL CHIP
4.7K
5%
1/16W
R110
1-216-845-11 METAL CHIP
100K
5%
1/16W
R111
1-216-837-11 METAL CHIP
22K
5%
1/16W
R113
1-216-833-11 METAL CHIP
10K
5%
1/16W
R114
1-216-833-11 METAL CHIP
10K
5%
1/16W
R115
1-216-833-11 METAL CHIP
10K
5%
1/16W
R116
1-216-833-11 METAL CHIP
10K
5%
1/16W
R117
1-216-833-11 METAL CHIP
10K
5%
1/16W
R118
1-216-833-11 METAL CHIP
10K
5%
1/16W
R125
1-216-841-11 METAL CHIP
47K
5%
1/16W
R130
1-216-073-00 METAL CHIP
10K
5%
1/10W
R131
1-216-073-00 METAL CHIP
10K
5%
1/10W
R201
1-216-797-11 METAL CHIP
10
5%
1/16W
R202
1-216-831-11 METAL CHIP
6.8K
5%
1/16W
R203
1-216-833-11 METAL CHIP
10K
5%
1/16W
R204
1-216-829-11 METAL CHIP
4.7K
5%
1/16W
R205
1-216-817-11 METAL CHIP
470
5%
1/16W
R206
1-216-817-11 METAL CHIP
470
5%
1/16W
(CA850)
R207
1-216-797-11 METAL CHIP
10
5%
1/16W
(CA850)
R208
1-216-832-11 METAL CHIP
8.2K
5%
1/16W
(CA850)
R209
1-216-821-11 METAL CHIP
1K
5%
1/16W
(CA850)
R210
1-216-853-11 METAL CHIP
470K
5%
1/16W
(CA850)
R211
1-216-797-11 METAL CHIP
10
5%
1/16W
(CA850)
R212
1-216-825-11 METAL CHIP
2.2K
5%
1/16W
(CA850)
R213
1-216-825-11 METAL CHIP
2.2K
5%
1/16W
(CA850)
R214
1-216-857-11 METAL CHIP
1M
5%
1/16W
(CA850)
R215
1-216-809-11 METAL CHIP
100
5%
1/16W
(CA850)
R216
1-216-833-11 METAL CHIP
10K
5%
1/16W
(CA850)
R217
1-216-833-11 METAL CHIP
10K
5%
1/16W
(CA850)
R218
1-216-809-11 METAL CHIP
100
5%
1/16W
(CA850)
R219
1-216-845-11 METAL CHIP
100K
5%
1/16W
(CA850)
R220
1-216-825-11 METAL CHIP
2.2K
5%
1/16W
(CA850)
R221
1-216-841-11 METAL CHIP
47K
5%
1/16W
R222
1-216-809-11 METAL CHIP
100
5%
1/16W
(CA850)
R222
1-216-864-11 SHORT
0
(CA850X/CA860X)
R223
1-216-809-11 METAL CHIP
100
5%
1/16W
(CA850)
R223
1-216-864-11 SHORT
0
(CA850X/CA860X)
R301
1-216-841-11 METAL CHIP
47K
5%
1/16W
R302
1-216-845-11 METAL CHIP
100K
5%
1/16W
R303
1-216-833-11 METAL CHIP
10K
5%
1/16W
R304
1-216-833-11 METAL CHIP
10K
5%
1/16W
R305
1-216-833-11 METAL CHIP
10K
5%
1/16W
R306
1-216-833-11 METAL CHIP
10K
5%
1/16W
R307
1-216-833-11 METAL CHIP
10K
5%
1/16W
R308
1-216-833-11 METAL CHIP
10K
5%
1/16W
R309
1-216-833-11 METAL CHIP
10K
5%
1/16W
R310
1-216-833-11 METAL CHIP
10K
5%
1/16W
R311
1-216-845-11 METAL CHIP
100K
5%
1/16W
(CA860X)
R312
1-216-833-11 METAL CHIP
10K
5%
1/16W
R313
1-216-864-11 SHORT
0
(CA850/CA850X)
R314
1-216-833-11 METAL CHIP
10K
5%
1/16W
R315
1-216-797-11 METAL CHIP
10
5%
1/16W
(CA860X)
R316
1-216-817-11 METAL CHIP
470
5%
1/16W
(CA860X)
R317
1-216-839-11 METAL CHIP
33K
5%
1/16W
(CA860X)
R318
1-216-837-11 METAL CHIP
22K
5%
1/16W
(CA860X)
R319
1-216-837-11 METAL CHIP
22K
5%
1/16W
(CA860X)
R320
1-216-817-11 METAL CHIP
470
5%
1/16W
(CA860X)
