Page 11
11
AF peak indication (SK 300 G2 only)
The yellow LED (AF PEAK)
¿
at the front of the SK 300 G2 lights up when the
audio input level is excessively high (AF peak) and overmodulates the
transmitter. At the same time, the 7-step level display for audio signal “AF”
shows full deflection for the duration of the overmodulation.
“PILOT” display
The “PILOT” display
ቧ
lights up when the pilot tone evaluation is activated.
(see “Activating/deactivating the pilot tone transmission or pilot tone
evaluation“ on page 33).
Display backlighting
After pressing a button, the display remains backlit for approx. 15 seconds.
¿
ቧ
