Tools required Tools are the first step to proper assembly,
you will need a
Allen / Hex key metric set
Philips head screwdriver
Open-end flat wrenches metric
measurements 6mm - 17mm
Front wheel Insert the hub motor wheel into the front fork,
ensuring that it is properly seated in the dropout slots. Tighten the
nuts alternatively on both sides till the wheel is secured.
Tightening torque
35 Nm
Seat post Insert into the seat tube of the bicycle frame
and align. Tighten clamps and ensure seat is firmly fastened.
Tigtening torque
16 Nm
Do not adjust the seat post beyond its maximum extension
mark.
Sprint Assembly
6
Handlebar / Stem / Headset Handlebar
and stem comes pre-assembled. Loosen
bolts on the stem and insert and turn the
handle bar assembly until it is in right angles
with the frame. Then tighten.
Tightening torque
18 Nm
