7

OPERATING INSTRUCTIONS

CONTROL PANEL & REMOTE OPERATION

1. Place the heater on a firm, level surface and plug into a grounded 120V 60Hz power outlet. Only operate

heater in upright position with caster wheels attached.

2. Turn the heater on by pressing the On/Off button on the control panel or the supplied remote control.

3. Select a heat setting:

On the control panel, press the MODE button to toggle between the two heat settings; LOW (750W) and
HIGH (1500W) . When using the remote control press either HIGH or LOW buttons to select the
preferred power setting.

4. Adjust the thermostat by pressing the arrows on the control panel or remote control. The digital readout

will display the selected temperature.

5. Once you have chosen the desired temperature, the heater will remain on until the room temperature

increases to the temperature on the digital display. The heater will cycle on and off to maintain the desired
room temperature.

6. This heater is equipped with a 12-hour automatic shut-off timer. To activate the timer, press the TIMER

button on the control panel or remote control. Each press of the timer button will increase the heater oper-
ating time by one hour. The digital readout will display the number of hours you have selected. To turn
off the timer, simply press the TIMER button until the digital readout displays your current selected
temperature.

7. The indication lights on the control panel communicate how the product is operating. The POWER light

will turn-on when the unit is operating. The TIMER light will turn on when the timer has been activated.

8. Unplug the heater when not in use.

Receiver for Remote Control

Timer Select Button

Temperature Select Buttons

Mode Select Button

On/Off Button (Power)

Temperature & Timer
Display

Indication Lights
