ConneXium
™ Ethernet Gateway
63230-319-211A1
ETG User Interface OVERVIEW
2/2006
© 2006 Schneider Electric. All Rights Reserved.
4
ENGLISH
ETG USER INTERFACE
OVERVIEW
The ETG ships with seven pre-installed web pages used for ETG setup and
configuration. See Table 1 for a description of each web page.
Table 1:
ETG static web pages
ETG Web Page
Description
See
Page
Setup
Ethernet & TCP/IP
Configure Ethernet and TCP/IP communication settings.
Serial Port
Set up or change serial communication parameters.
Device List
Identify serial devices on the daisy chain.
User Accounts
➀
Create and edit groups and users.
Web Page Access
➀
Select web page access rights for each user group.
Modbus TCP/IP Filtering
➀
Set up which IP addresses can access the ETG through
Modbus TCP/IP.
SNMP Parameters
➀
Enable and configure the Simple Network Management
Protocol (SNMP), which allows the ETG to identify itself
to network devices requesting SNMP data.
Diagnostics
Statistics
Displays diagnostic data used to troubleshoot network
problems. This page also contains information about
your specific ETG, including the serial number,
manufacturing date, and Media Access Control (MAC)
address.
Read Device Registers
Allows ETG administrators to read register data from a
serial device connected to the ETG.
➀
Accessible by administrator only
