Connecting for audio signal, Installation – Sanyo PJLINK PLC-ZM5000L User Manual
Page 21
Unplug the power cords of
both the projector and external
equipment from the AC outlet
before connecting cables.
Cables used for connection ( = Cables not supplied with this projector.)
Installation
• Audio cables
Audio
Output
AUDIO IN 1/2
Audio Output
Audio
cable
(stereo)
(R) (L)
External Audio Equipment
Audio Input
AUDIO OUT
(stereo)
(R) (L)
(R) (L)
Audio
cable
Audio
cable
(stereo)
Audio
cable
(stereo)
Connecting for Audio Signal
21
