Flush inset panel application—110° door opening – Sub-Zero 601RG User Manual
Page 40
DOOR OPEN 110˚
SUB-ZERO UNIT
CABINETRY
FLUSH INSET PANEL
3
/
4
"
(19) THICK
(TYPICAL)
1
/
4
"
(6)
PANEL
1
1
/
4
"
(32
)
P
A
NEL
3
/
4
"
(19
)
P
A
N
EL
1"
(25
)
P
A
N
EL
1
1
/
4
"
(32)
ASSUMES
3
/
4
"
(19)
FLUSH INSET
PANEL
THICKNESS
2
3
/
16
"
(56)
24"
(610)
TO BACK WALL
MAIN FRAME
TOP VIEW
This full-scale template
shows what considerations
you need to make for flush
inset panel applications and
how they may interact with
adjacent cabinets and
countertops.
IMPORTANT NOTE: For
flush inset panels thicker
than
3
/
4
" (19), a 90˚ door
stop may be needed to
avoid interference with
adjacent cabinets.
Dimensions in parentheses
are in millimeters unless
otherwise specified.
Flush Inset Panel Application—110° Door Opening
40
Full-Scale
T
emplates
