C3X LITE C3X C3X LINK
INPUTS/OUTPUTS
S-Video (mini DIN 4 pins) 1 1 2
Composite Video (RCA) 1 1 2
RGBS-YCrCb (4 RCA) 1 1 -
RGBHV/YCrCb (5 RCA) - - 3
RGBHV/YCrCb (5 BNC) - - 1
RGBHV (D-Sub 15 pin) 1 1 2
HDMI™-HDCP compliant 1 1 1
OUT Digital Audio (Toslink) 1 1 1
USB connector 1 1 -
DVI (DVI-D) - - 1
RS232 (D-Sub 9 pin) 1 1 1
12 V 100 mA (via jack) 2 2 2
Input External IR sensor 1 1 1
GENERAL SPECIFICATIONS
Software control: upgradable via RS232, serial interface or USB • • •
Weight: 11 Kg. or 24.3 lbs • • •
Dimensions (WxHxD): 435x190x430 mm (17.2”x7.5”x16.9”) • • •
Mains voltage range: 100÷240 +/-10% (48/62 Hz) • • •
SUPPLIED ACCESSORIES
Installation and User Manual • • •
AC power cords (EU, UK, USA) (2m or 6.6 ft.) • • •
Backlit remote control and batteries • • •
DigiOptic™ Image Processor - - •
Fiber optics cable (20m or 65.6 ft.) - - •
C3X LITE C3X C3X LINK
LIGHT ENGINE
DLP® Type: 3 Chip DMDs HD2+ DC3 • • •
Resolution: 1280x720 pixels • • •
Lens: High quality, high resolution improved optics for higher contrast
and better black level with both motorized zoom and focus adj.
Lamp power consumption: 150W dimmable 250W dimmable 250W dimmable
to 132W to 200W to 200W
INSTALLATION
Throw ratio: 2,0-3,0:1 (standard lens - type T2) • • •
1,5-2,0:1 (type T1 – on request)
Lens shift: half up picture =+50% • • •
Digital keystone adjustment • • •
Picture size (inches diagonal): 50-250 50-300 50-300
Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox, panoramic,
pixel to pixel + 3 custom-user adjustments
ELECTRONICS
Horizontal & vertical scan freq.: 15-80kHz/48-100Hz • • •
SDTV: PAL (B,G,H,I,M,N,60); SECAM; NTSC 3,58;
NTSC 4,43 automatically selected
HDTV: ATSC (480p, 720p, 1080i); 576p + 1080i 50Hz
PC graphic standard: VGA, SVGA, XGA, SXGA, UXGA @ 65Hz
On Board Video Processing • • •
Contrast ratio (Full ON/ Full OFF): 5500:1 6500:1 6500:1
Due to constant product development, specifications and design might be subject to change without notice.
