- 14 -
standards of the physical layer of IrDA
(Ver1.2).
(6) Interface connector
Connects with the interface cable. Open
the rubber cover and insert the connector.
(7) Paper outlet
Paper port with a paper cutter.
(8) Thermal head
The thermal head prints characters on the
thermal paper. It is very hot immediately
after printing.
(9) Paper sensor
The sensor that detects thermal paper
existence or paper mark.
(10) Paper cover open button
The button that is used as opening the
paper cover when setting the thermal
paper.
(11) Paper cover
The platen roller is released from the
thermal paper after opening this cover.
Open this cover to replace the thermal
paper or to clean the thermal head.
(12) Platen roller
The platen roller brings the paper in
contact with the thermal head. The platen
roller is turned to feed the paper.
(13) Power connector
Connects the AC adapter to this
connector.
(14) Paper slot
Paper inlet for the paper sheet.
(15) Battery release lever
Releases the battery pack from the printer.
(16) Battery cover
Covers and Holds placed battery pack in
the printer.
