P
ARTS M
ODEL
300 R
ESTAURANT
R
ANGES
Shelf and Flue Riser Parts for Models 348 and 360
1
2
Key Part Number Description
1 1180845 Shelf weld assembly, 60"
* 1181140 Shelf weld assembly, 48"
2 1180768 Flue riser assembly, 22.5" x 60"
* 1181152 Flue riser assembly, 10" x 60"
* 1181136 Flue riser assembly, 22.5" x 48"
* 1181153 Flue riser assembly, 10" x 48"
* not shown on drawing.
P AGE 46 O PERATOR ’ S M ANUAL 1182298 REV 3
PARTS
