Using Nucleus’ Analogue IO
For soundcards which don’t have digital IO, line-level analogue connections allow you still to make use of Nucleus’ SSL pre-
amps. Nucleus PRE (pre-amp) outputs and EXTERNAL monitor inputs can be used to connect Nucleus to the soundcard inputs
and outputs.
Ethernet
(DAW control
and Remote)
USB
(DAW keyboard
commands)
DAW
Computer
Recording
Sources
Note.
Socket locations are approximate
Mains
Power
Monitoring
Headphones
PRE Out
and
EXTERNAL
In
MP3
Player
