5 931155 Rev. A
1 1 1 . Y O U R C H A I R A N D I T S P A R T S
Q U I C K I E G - 4 2 4 I N T E G R A T E D C . G . T I L T
1. Push Handle
2. Dual Post, Height-Adjustable
Armrest
3. Remote Joystick
4. Seat Pan
5. Swing-Away Footrest Latch Plate
6. Swing-Away Footrest Hanger
7. Angle-Adjustable Footplate
8. Seat Back
9. Shroud
10. 14" Drive Wheels
11. Caster Housing
12. 7" Solid Casters
13. Caster Fork
14. Headrest
15. Tilt Toggle Switch (not shown)
4 931155 Rev. A
1 1 . T A B L E O F C O N T E N T S
1. INTRODUCTION NOTE........................................................................3
11. TABLE OF CONTENTS..........................................................................4
111. YOUR CHAIR AND ITS PARTS ..........................................................5
IV. WARNINGS....................................................................................................7
A. Solid Seat Back ............................................................................................7
B. Driving ..........................................................................................................7
C. Tilting ............................................................................................................7
D. Changes & Adjustments ............................................................................7
E. Locking Pins ................................................................................................7
V. SET UP, ADJUSTMENT & USE............................................................8
A. Battery Removal ..........................................................................................8
B. Solid Seat Back & Lateral Thoracic Supports ......................................9
C. Headrest ......................................................................................................9
D. Foam Back..................................................................................................10
E. Seat Tilt Adjustments & Drive Lock-out ............................................10
F. Seat Removal ............................................................................................11
G. Seat Depth ................................................................................................11
H. Backrest ......................................................................................................12
I. Seat Height Adjustment ..........................................................................12
J. TM40 Single or Dual Switch Actuator Controller ..........................12
K. Check-Out ................................................................................................13
VI. OPERATING GUIDE ..............................................................................14
A. Toggle Switch Activation ........................................................................14
B. Single Switch Activation ..........................................................................14
C. Integral Joystick Activation ....................................................................14
D. Remote Joystick Activation ....................................................................14
VII. MAINTENANCE & TROUBLESHOOTING TIPS......................15
A. Maintenance ..............................................................................................15
B. Troubleshooting Tips ..............................................................................15
VIII. WIRING DIAGRAMS..............................................................................16
IX. SUNRISE LIMITED WARRANTY......................................................18
1
2
14
13
12
11
10
9
8
7
6
5
4
3
