LOCATION OF CONTROLS
Unit back view
2
1
3
4
5
1
1. Bass reflex hole
2. FM antenna
3. Time back up battery
cover
4. Ethernet jack
5. DC IN 12V jack
Unit front view
1. Speakers
2.
ALARM OFF button
3. (
) ON/STANDBY button
4. Preset P1 button
5. Preset/Previous
P2/
button
6. Preset/Play/Pause
P3/
button
7. LCD display
8. Preset/Next
P4/
button
9. Preset/Stop
P5/ button
10. VOLUME + button
11. VOLUME - button
12. Interchangeable inlay
13. SD/MMC card slot
14. RECORD
button
15. USB port
16. Repeat/Shuffle
/
button
17. SCROLL/SELECT/SNOOZE knob
18. BACK button
19. Headphones jack
20. AUX IN jack
21. IR (Infra-red) remote control sensor
2
1
3
4
5
6
7
8
9 10 11 1
21 20 19 18 17 16 15 14 13 12
