Aac cc ce es ss so orriie es s, Ssp pe ec ciiffiic ca attiio on ns s, Instruction manual – StarTech.com RS-232 User Manual
Page 15
S
Sp
pe
ec
ciiffiic
ca
attiio
on
ns
s
A
Ac
cc
ce
es
ss
so
orriie
es
s
USBBTOOTH1
USB to Class 1 Bluetooth Adapter
USBBTOOTH2
USB to Class 2 Bluetooth Adapter
NM9FF
Null Modem Adapter DB9 Female to DB9 Female
NM9MM
Null Modem Adapter DB9 Male to DB9 Male
SCNM9FM
10 ft. Cross Wired Serial/Null Modem Cable DB9 F/M
SCNM9FF
10 ft. Cross Wired Serial/Null Modem Cable DB9 F/F
Instruction Manual
12
Connectors
1 x Serial port (DB9 male)
Maximum Data Transfer Rate
9,600 to 460,800 bps
Chipset
Maxim MAX3238E
OS Support
Supports Windows 98SE / ME / 2000 / XP or later
Operation Temperature
0 to 60 Degrees C
Storage Temperature
10 to 70 Degrees C
Modulation Method
GFSK, 1 Mbps, 0.5BT Gaussian
Sensitivity
<-88dBm at <0.1% BER
Power Consumption
Tx Typical: 115mA
Rx Typical: 75mA
Standby Mode: 15mA
I/O Interface
RS-232 DTE Mode
Signal type(s)
RxD, TxD, RTS, CTS, DTR, DSR, DCD, GND
