Page 3
3
TP-400-2331-00-AT-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693706
54” Turbo
54” Turbo
1
1927557
8
FLANGE LOCKNUT, 5/16-18
2
1672689
1
S-HOOK
3
1933988
3
PUSH NUT, 5/16-18
4
1706630
1
STRAP
5
1720892
1
HOUSING, With Decal
6
1700259
1
DECAL,Danger
7
1919438
1
NYLOCK NUT, 5/16-18
8
1720932
1
V-BELT
9
1960472
6
SCREW, Truss Head, 1/4-20
10
1921961
1
CAPSCREW, Hex, 1/4-20 x 1-1/4
11
1921319
1
WASHER, 1/4
12
1665982
4
RETAINER, Bearing
13
108202
2
BEARING
14
1931333
5
CARRIAGE BOLT, 5/16-18 x 3/4
15
1706631
1
FAN ASSEMBLY
16
1921332
3
CAPSCREW, Hex Head, 5/16-18 x 3/4
17
1706634
1
PULLEY
18
1960619
1
SET SCREW, Torx, 5/16-18 x 5/16
19
960403
1
KEY, Woodruff
20
1921969
1
CAPSCREW, Hex Head, 3/8-16 x 1-1/2
21
1924940
4
WASHER, 3/8
22
174561
1
PULLEY, Idler
23
1720918
1
COVER
24
1916965
2
LOCKWASHER, 3/8
25
1916950
2
NUT, 3/8-16
26
1923701
1
CAPSCREW, Hex Head, 3/8-16 x 2
27
1666114
1
BUSHING
28
1720934
1
LEVER ASSEMBLY
29
1922755
1
WASHER, 3/8
30
1704419
1
BELT STOP
31
174896
1
SPRING, Extension
32
1720721
1
PLATE & BRACKETS ASSEMBLY
33
1930641
8
LOCKNUT, 1/4-20
34
1930645
1
NUT, Hex, 3/8-16
35
1927429
3
SCREW, Taptite, 1/4-20 x 5/8
36
1720718
2
PILOT PIN, Tapered Spacer
37
1720951
1
ROD & ANCHOR ASSEMBLY, Deflector
38
1720921
3
LOCKING TAB
39
1719590
1
SPRING, Extension
40
1933896
4
LOCKNUT, 10-24
41
1960404
4
SCREW, Truss Head, 10-24 x 3/4
42
1927120
1
CAPSCREW, Hex Head, 7/16-14 x 2-1/4
43
1720737
1
PULLEY & HUB ASSEMBLY
44
1921959
4
CAPSCREW, Hex Head, 1/4-20 x 5/8
45
1720978
1
SPACER, 5/8 x 1
46
1704628
2
PIN, Spring
47
1916964
4
LOCKWASHER, 1/4
48
1916622
4
NUT, Hex, 1/4-20
49
1931320
1
CARRIAGE BOLT, 1/4-20 x 1-1/4
