Southbend HEAVY DUTY COUNTERLINE HDG-48 - Manual (Page 7)

H EAVY D UTY C OUNTERLINE
I
NSTALLATION
O WNER ’ S M ANUAL 1192662 P AGE 7
INSTALLATION
Step 2a: Installation on Countertop Legs
To install the appliance using countertop legs, do the following:
1. Locate the box of four legs shipped with the appliance (if countertop legs were ordered).
2. Raise the appliance about 6" so that the legs can be screwed into the bottom near the corners. Lift the
appliance only from the ends, never from the middle! Support the lifted appliance so that it will not fall
while you are attaching the legs.
3. Screw the four legs into the threaded holes located on the bottom of the appliance near each corner
(as shown in Figure 2 below).
Gently lower the appliance onto the counter. Level the appliance surface by screwing one
or more of the legs in or out.
4. Step 4 on page 10.
Figure 2
