Page 61
12/99
61
H
ANDLEBAR
AND
C
ONTROLS
Model 907254
Item Part No.
Qty.
Description
1
01177244
1
Engine Bail Weldment
2
06437200
7
Washer-Flat Steel .344 x .688 x .065
3
05514500
4
Bushing-Flange .325 x .688 x .560
4
07517000
2
Cap, Vinyl .25 I.D.
5
01177044
1
Traction Bail
6
01183144
1
Handlebar, Self Propelled
7
06922000
1
Engine Control Cable
8
01137544
1
Cable Anchor-Right Hand
9
01155700
1
Cable Anchor-Left Hand
10
06220100
2
Bolt-Round Head Square Neck .25-20 x 1.25
11
06529700
4
Nut-Locking-Center .25-20
12
07517300
3
Cable Tie
13
01141844
1
Brace-Speed Control
14
01137444
1
Bracket-Speed Control
15
01150044
1
Link-Handlebar Adjuster Left Hand
01150144
1
Link-Handlebar Adjuster Right Hand
16
01178700
6
Washer-Bellville Spring
17
05514900
2
Bushing-Flange .325 x .500 x .513 x .875
18
06529800
4
Nut-Locking-Center .31-18
19
06222300
1
Bolt-Round Head Square Neck .25-20 x 1.38
20
06220600
1
Bolt-Round Head Square Neck .25-20 x .50
21
07515900
1
Knob
22
01140800
1
Rod-Speed Control
23
06921200
1
Traction Cable
24
06216100
2
Bolt-Round Head Square Neck .31-18 x .75 Grade 5
25
01305900
2
Shoulder Spacer
26
06215700
2
Bolt-Round Head Square Neck .31-18 x 1.00 Grade 5
27
06529600
1
Nut-Locking-Center .38-16
28
06436200
2
Washer-Flat-Steel .406 x .812 x .065
29
06306500
2
Washer-Lock .375 x .115 Heavy
30
01154800
1
Pressure Flange
31
06437300
1
Washer-Flat-Steel .281 x .620 x .065
32
06712400
1
Pin-Cotter .06 x .50
33
01126100
1
Shift Link
34
01123945
1
Bell Crank-Speed Control
35
01123800
2
Friction Washer
36
01019800
1
Cap, 3.8 Rod
37
01139800
1
Swivel
38
06222200
1
Bolt-Round Head Square Neck .38-16 x 1.50
39
06713500
1
Pin-Hair-Internal .08 x .18 x 1.18
40
01173800
1
Support Pad
41
06815700
2
Rivet .187 x .575
42
06442700
2
Washer-Flat Steel .219 x .50 x .049
