4
5. Change JP1-JP4 jumper settings to the desired
voltage only if your serial device(s) needs additional
power from the serial port. However, most serial
devices do not require additional power. For more
information, see Figure 1 on page 2. Skip this step
if power is not required.
6. To install the card, carefully align the card's bus
connector with the selected PCI slot on the
motherboard. Push the board down firmly, but
gently, until it is well seated.
7. Replace the slot bracket's holding screw to secure
the card.
8. Replace the computer cover and reconnect the power
cord.
9. Connect the 4-port fan-out cable to the board's
44-pin connector. For more information, see Figure
2 on page 3.
Driver Installation
This section provides information on how to install the
CyberPro PCI 4S drivers.
Windows 95
1. At the Update Device Driver Wizard window, click
Next.
2. Insert the driver CD, and click Other Locations.
Type in D:\9x, click OK, then Finish. (Change D: to
match your CD-ROM drive letter)
3. From the Insert Disk window, click OK. When the
Copying Files dialog box appears, type in
D:\9x, then click OK.
4. Restart Windows to complete the installation.
