Side view
\
FUSE
Underside View
4
1.
2.
3.
4.
5.
6.
7.
6.
9.
Key to
Connected to fuse or circuit breaker, then battery’s positive post.
Ground Main ground connection. Bolt to a clean chassis ground in the
vehicle.
Remote Remote turn-on input from the head unit. Accepts
LED Indicates amplifier power on.
Speaker Connections Channels 1 2
Input Level Variable from to
Inputs Right and left channel inputs; only right channel input used in
“Mono” mode.
[underside] Stereo/Bridged Mono Switch Select “Mono” for bridged
operation (use only right channel input or stereo position for 2-channel
Stereo or Mixed Mono operation).
[underside] Amplifier Crossover Switch Select low pass or full range
operation.
10. [underside] Main Fuse Main power supply fuse. Replace only with same
fuse value.
