Sterling Plumbing 71100116 User Manual
Ensemble, Features, Codes/standards applicable

Features
• Compression molded from our exclusive solid Vikrell
®
material
• Tongue-and-groove 4-piece modular design allows for
easy
″snap together″ installation
• Gentle sloping back, neck, and armrest in bath
design
• Bath and integral apron eliminates installation step
• Durable high-gloss finish
• 10-year consumer/3-year commercial limited warranty
• Available with above-the-floor drain
• Wall surround allows for attachment of grab bars
• 60-1/4″ (1530 mm) x 37-1/2″ (953 mm) x 73-1/4″
(1861 mm) complete unit rough-in dimensions
• 60″ (1524 mm) x 36″ (914 mm) x 72″ (1829 mm)
complete unit finished dimensions
Codes/Standards Applicable
Specified model meets or exceeds the following:
• ASTM E162
• ASTM E662
• CSA B45.5/IAPMO Z124
36
″ (914 mm) OVAL BATH/SHOWER
SYSTEM WITH BACKER BOARDS
71100116
ALSO 71100118, 71100126, 71100128
Colors/Finishes
•
0: White
•
Other: Refer to Price Book for additional colors/finishes
Specified Model
Model
Complete Unit Description
Colors/Finishes
71100116
36
″ (914 mm) oval bath/shower system and wall surround with backer boards, left
drain
❑ 0
❑ Other____
71100118
36
″ (914 mm) oval bath/shower system and wall surround with backer boards,
above-the-floor left drain
❑ 0
❑ Other____
71100126
36
″ (914 mm) oval bath/shower system and wall surround with backer boards, right
drain (shown)
❑ 0
❑ Other____
71100128
36
″ (914 mm) oval bath/shower system and wall surround with backer boards,
above-the-floor right drain
❑ 0
❑ Other____
Model
Wall Component Description
Colors/Finishes
71104106
Complete wall set with backer boards
❑ 0
❑ Other____
ENSEMBLE
TM
Page 1 of 2
1065810-4-
F
For more information
visit SterlingPlumbing.com
or call 1-800-STERLING
