Sioux Tools 2050 - Manual (Page 50)

D
C
B
A
B
C
D
1 2 3 4 5 6 7 8
8 7 6 5 4 3 2 1
REVISIONS
REV. DATE CHK BY DESCRIPTION ECN
REV B DWG NO. MON700230
DO NOT SCALE DRAWING
DRAWN
DATE CHECKED
SCALE BREAK ALL EDGES
.03 X 45
FRACTIONAL 1/32 3 PLACE .005
2 PLACE .020 ANGULAR 1
DIMENSIONS ARE IN INCHES
TOLERENCES UNLESS SPECIFIED
MATERIAL
PROPERTY OF
SIOUX AUTOMATION CENTER INC.
877 FIRST AVE NW SIOUX CENTER, IA 51250
REV DWG NO. SIZE
B
JL DATE 12-00
1:3
AS SHOWN
MON700230
B
CHUTE,FLIP,CYL,ASSY
SHEET OF
1 1
744
A
B JL
VM
12-00
2-95 MON700253 WAS MON700189
MON100955 WAS MON100251
HYD6801-6-6 WAS HYD6400-6-8
9
9
7
2
11
11
3
1 8
7
10
4
5
6
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 MON100393 BRKT,RAM,CLY,CHUTE
2 1 MON100955 CYL,HYD,2,8,W/CNTRBAL,PAINTED
3 1 NUT34JAMNF NUT,HEX,JAM,3/4,NF,G8
4 2 BLT38X1CNC BLT,CARR,3/8,1,NC,G2
5 2 WSH38LOCK WSH,LOCK,3/8
6 2 NUT38NC NUT,HEX,3/8,NC,G5
7 2 SPCP316X112 PIN,COTTER,3/16,1-1/2
8 1 SPBUS58NR14G BUSHING,MACH,.625,NR,14GA
9 2 MON700253 HOSE,HYD,3/8,62
10 1 MON700171 BRKT,CHUTE,FLIP
11 2 HYD6801-6-6 ADPT,ELBOW,06,MJIC,06,MORG,90D
