Soleus Air PH4-12R-01 - Manual (Page 3)

3
SPECIFICATIONS
• The cooling capacity is measured at an ambient temperature of DB 86 °F, WB 78 °F.
• Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
• If the environment temperature is higher than the max operating temperature or lower than the minimum operating temperature,
the air conditioner may not work properly.
PACKAGE CONTENTS
MODEL PH4-10R-01 / PH4-12R-01
COOLING CAPACITY 10,000 / 12,000 BTU/H
HEATING CAPACITY 10,000 / 12,000 BTU/H
DEHUMIDIFYING CAPACITY 50 / 60 pts/Day
POWER
COOLING 1200W/1350W
HEATING 950W/1160W
AIR FLOW VOLUME 225 CFM
POWER SOURCE
115 V~ 60 HZ
8.6/10.8 AND 10.5/12 AMP
HEATING/COOLING
SOUND PRESSURE LEVEL 42/46 dB(A)
NET WEIGHT 76/82 Lbs
OPERATING
TEMPERATURE
COOLING 60.8℉-107.6℉
HEATING 23℉-89.6℉
DIMENSIONS
ASSEMBLED 19” W ×32.25” H ×18.5” D
PACKAGE 22.6” W ×34.3” H ×21.4” D
REFRIGERANT R22
Portable Air Conditioner
Exhaust Hoses (2)
Hose Adapters (2)
Window Kit Adapter (2)
Remote Control
AAA Batteries (2)
Window Kit - 4 Sliding Panels (1 dual hose panel, 1 single hose panel, 2 extension panels)
Air Intake and Outlet Covers (2)
Air Intake Vent for Single Hose Installation (Additional Accessory) (1)
Owner’s Manual
