background image

Color Indoor Dome Camera w/Built-In IR

LEDs and Anti-Reflection Technology

Specifications

Resolution

. . . . . . . . . . . . . . . . . . .

420 lines

Image Device

. . . . . . . . . . . . . . . . .

1/3" Sony Super HAD* color CCD

Minimum Illumination

. . . . . . . . . . .

0 lux with IR on, 1.0 lux with IR off

Electronic Shutter

. . . . . . . . . . . . . .

Auto 1/60-1/100,000 sec.

Lens

. . . . . . . . . . . . . . . . . . . . . . .

3.6mm lens (optional lenses available)
Varifocal version only - 4-9mm auto iris

Synchronization

. . . . . . . . . . . . . . .

Internal 2:1

Scanning System

. . . . . . . . . . . . . . .

EIA standard 525 line 60 fields/second

S/N Ratio

. . . . . . . . . . . . . . . . . . .

Greater than 48 db

Back Light Compensation

. . . . . . . . .

Auto

AGC

. . . . . . . . . . . . . . . . . . . . . . .

Auto

Gamma Characteristic

. . . . . . . . . . .

0.45 typ.

Video Output

. . . . . . . . . . . . . . . . .

1.0 Vp-p, 75 ohm

Operating Temperature

. . . . . . . . . . .

14˚F to 120˚F

LED IR Wave Length

. . . . . . . . . . . . .

850 NM

Number of LED

. . . . . . . . . . . . . . . .

22 IR LEDs

Effective IR range

. . . . . . . . . . . . . .

60’ (depending on scene reflection)

Power Supply

. . . . . . . . . . . . . . . . .

12V DC regulated - included UL approved

Dimension

. . . . . . . . . . . . . . . . . . .

5” Diameter x 3”H

Weight

. . . . . . . . . . . . . . . . . . . . .

8 oz.

Case

. . . . . . . . . . . . . . . . . . . . . .

High impact ABS

*Super HAD is a trademark of the Sony Corporation

Specifications subject to change

For more information contact us at:

Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com

Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880

Package Includes:

VL-648IR or VL-648IRVF Camera

Instructions

Warranty card

Power Supply

Features

VL-648IR

3.6mm lens
(optional lenses available)

VL-648IRVF

Comes with 4-9mm
auto iris varifocal lens

The VL-648IR is a color day/night camera with special shielding to eliminate IR reflections.
It is used for indoor ceiling applications to cover the full spectrum of bright light to no
light surveillance. This dome camera can be wall or ceiling mounted by using the matching
bracket that is included in the box.
