Page 14 GPS Chart 150C
Figure 2.4a - Inserting C-CARD (II)
NOTE
Throughout this Owner's Manual, the keys are noted in Capital bold letters with
quotes, example “ENTER”. Menu operations are in Capital bold letters that are
underlined, example: ADVANCED SETUP.
For an example “MENU” + ADVANCED SETUP + “ENTER” + INPUT/OUTPUT
+ “ENTER” means:
1. Press the key.
2. Use the ShuttlePoint knob to select the ADVANCED SETUP menu item.
3. Press the key.
4. Use the Shuttlepoint to select the INPUT/OUTPUT menu item.
5. Press the key.
2.5 CONTROLS AND INDICATORS
NOTE
This section defines each control of the chart plotter. For instructions, refer to
Getting Started and Advanced Operation sections of this Owner's Manual.
2.5.0 Controls and Connections
The chart plotter is controlled by using the 10 keys located on the front panel of the
CP150C. There is also a ShuttlePoint knob to move the cursor across the screen. As
