Page 7
07/03
P/N 211696
7
PARTS LIST - (See Hardware Identifier)
ItemQty. Part No. Description
1
1
206657
Tank, (Black)
2
1
200628
Wheel Axle
3
2
226401
Wheel, 4“ (Black)
4
1
918070
Top Pole Section (Straight Piece)
5
1
918071
Upper S-Pole Section
6
1
918072
Middle S-Pole Section
7
1
918073
Bottom S-Pole Section
8
1
202820
Rod, 3/8 O.D. x 4-3/4 Long
9
1
202822
Eyebolt, 3/8-16 x 2-1/2 Long
10
1
200627
Wheel Bracket
11
4
201651
Spacer .500 I.D. x .25 Long
12
3
203063
Nylon Insert Lock Nut, 3/8-16
13
1
203124
Stake, Tie Down
14
10
202201
Washer, Curved, 1/2" I.D.
15
2
918074
Tank Strut
16
6
202199
Nut, Sleeve, Allen Head, 5/16-18
17
6
202197
Bolt, Allen Head, 5/16-18 x 3" Long
18
6
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
19
6*
203218
Washer, Flat, 3/8 I.D.
20
8*
203100
Nut, Hex Flange, 5/16-18
21
2
202294
Allen Wrench 1/4"
22
2
200874
Spacer, .402 I.D. x .5 O.D. x 1.5" Long
23
3
203220
Nylon Insert Lock Nut, 5/16-18
24
3
206360
Bolt, Hex 3/8-16 x 2.65 Long
25
2
900964
Backboard Bracket
26
1
201129
Spacer .402 I.D. x .500 O.D. x 1.75 Large
27
1
201160
Pawl Lever
28
4
908002
Elevator Tubes
29
4
201642
Spacer .530 I.D. x.5 O.D. x .63 Long
30
5
206304
Bolt 1/2-13 x 6-5/16 Long
31
1
201159
Ratchet
32
5
206340
Nut 1/2-13
33
1
206305
Clevis Pin 1/4 x 2-9/32 Large
34
2
206303
Washer 1/4 Flat
35
1
201125
Return Ratchet Spring
36
1
203796
T-Bolt, 3/8-16 x 5” Large
37
1
900033
Bracket Slam Jam
38
1
206219
Cap, Pole Top 3”
39
1
Rim
40
1
200318
Bracket, Reinforcement, Slam Jam
41
1
203472
Spring, Black, Slam Jam
42
1
203470
Washer Flat, Slam Jam
43
1
203795
Nut, Special, Slam Jam
44
12
201219
Clip, Net Holder
45
1
Net
46
1
201257
Label, Height Adjustment and Moving
47
2
203617
Plug Cap
48
1
201568
Anchor, T-Strap
NOTE: Hardware kit is designed for more than one style of basketball system.
Not all hardware will be used.
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
