Warning – Spalding M8860411 User Manual
Page 5
5
08/06
ID# M86724C1
Ensure ground is level with playing surface, then dig pole hole.
CONTACT UTILITIES
BEFORE DIGGING.
WARNING!
24" (61 cm)
48" (121.9 cm)
PLAYING SURFACE
GROUND SURFACE
24" (61 cm)
48" (121.9 cm)
1.
2.
Install nuts (9) onto the ground tube bolts as shown.
2
9
Nuts on the top of the plate are
used for leveling the pole after
system is fully assembled.
NOTE:
