18

TECHNICAL SPECIFICATIONS

MODEL

PH1-14R-03

(Reference#: KY-36)

PH1-12R-03

(Reference#: KY-34)

Cooling Capacity

14,000 BTU/Hr

12,000 BTU/Hr

Heating Capacity

14,200 BTU/Hr

12,200 BTU/Hr

Dehumidifying Capacity

65 pts/day

63 pts/day

Power Consumption

Cooling

1390 W

1340 W

Heating

1180 W

1090 W

Air Flow Volume

328CFM

280CFM

Power Source

115 V / 60 HZ

115 V / 60 HZ

Rated Current

Cooling

12 A

11.7 A

Heating

9.8 A

9.5 A

Sound Pressure Level

<49 db(A)

<49 db(A)

Weight

80 lbs

80 lbs

Dimensions

14.4 W x 22.4 D x 30.5 H inches

14.4 W x 22.4 D x 30.5 H inches

Refrigerant

R22

R22

DISCLAIMER

ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL
ARE THE PRESENTATION OF THE MANUFACTURER. SOLEUS INTERNATIONAL HAS NOT
CONDUCTED INDEPENDENT TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED
HEREWITHIN.
