10
• Amplifier Section
Power output, stereo mode, 8 Ω, THD 0.02 %, 1 kHz | 2 125 W
4 Ω, THD 0.02 %, 1 kHz | 2 170 W
7-CH mode(full channel driven), 8 Ω, THD 0.02 %, 1 kHz | 7 100 W
4 Ω, THD 0.02 %, 1 kHz | 7 150 W
7-CH mode(only channel driven), 8 Ω, THD 0.02 %, 1 kHz | 130 W/CH
4 Ω, THD 0.02 %, 1 kHz | 200 W/CH
Total harmonic distortion, 8 Ω, 125 W, 1 kHz | 0.02 %
Intermodulation distortion
60 Hz : 7 kHz= 4 : 1 SMPTE, 8 Ω, 125 W | 0.01 %
Input sensitivity, 47 k Ω | 1.0 V
Signal to noise ratio, IHF “A” weighted
100 W, 8 Ω, 0 dB | 115 dB
1 W, 8 Ω, 0 dB | 100 dB
Frequency response, 20 Hz~100 kHz | +0, -1 dB
Damping factor | 100
• General
Power supply | 230 V ~ 50 Hz
Power consumption | 1000 W
Dimensions (W H D) | 440 196 450 mm(17-3/8 7-3/4 17-3/4 inches )
Weight (Net) | 32 kg (70.6 Ibs)
Note: Design and specifications are subject to change without notice for improvements.
Specifications
ENGLISH
