Heating Elements
Model No. Volts HZ 1 Phase Amps Watts Above Belt Below Belt NEMA
RCS2-1200B 208 60 15.9 3200 2 2 L6-20P
240 60 13.8 3200 2 2 L6-20P
220 50 15.0 3200 2 2 Not supplied with cord and plug
Dimensions Shipping Shipping Carton
Width Depth Height Weight Width Depth Height
Inches Inches Inches lbs. Inches Inches Inches
Model No (cm) (cm) (cm) (kg) (cm) (cm) (cm)
RCS2-1200B 14-1/2 22-3/8 15-5/8 64 20 18-7/8 25-3/8
(36.8) (56.8) (39.7) (140.8) (50.8) (47.9) (64.4)
Specifications
High performance Bagel Fast conveyor toaster is constructed of corrosion resistant stainless steel. Supplied with heavy-duty
motor, drive chain and Calrod heaters. A conveyor belt tension system is supplied for a smooth, quiet operation. Unit is sup-
plied with variable speed control, power saver and high limit switch. Extended conveyor belt, crumb tray, heated holding area
and full width burn guard is standard. Unit has a one-piece cover for easy access with 1" adjustable legs and a 4' cord. Unit is
listed with UL, CUL and are UL certified to NSF4. Patent number D459,140. Printed in the U.S.A.
RCS BAGEL FAST
CONVEYOR TOASTER
Performance Data
Electrical Data
Model No. Production Capacities Product Opening
RCS2-1200B 1200 bagel halves per hour 1-1/2”
Typical Specifications
S t a r M a n u f a c t u r i n g I n t e r n a t i o n a l , I n c .
Phone: (800) 264-7827 - FAX: (800) 264-6666 - www.star-mfg.com
Star Manufacturing International, Inc. - 10 Sunnen Drive - P.O. Box 430129 - St. Louis, MO 63143-3800
Due to periodic changes in designs, methods, procedures, policies and regulations, the specifications contained in this sheet are subject to change without notice. While Star
Manufacturing exercises good faith efforts to provide information that is accurate, we are not responsible for errors or omissions in information provided or conclusions reached as
a result of using the specifications. By using the information provided, the user assumes all risks in connection with such use.
