Skylink G6T3 - Manual

1. INTRODUCTION
3-Button Garage Door
Remote Control
Model G6T3
In this package, you will find a Skylink
®
garage door transmitter with 3V
lithium battery, a mounting bracket, a visor clip and a double sided tape.
You need to do the programming in order to add the transmitter - remote
control to a receiver.
Refer to the receiver Smart Button TM GB-318 user’s instruction to set up the unit.
2a. PROGRAM TRANSMITTER TO RECEIVER GB-318
Garage Door
Transmitter
(Battery inside)
3 Volt lithium battery (CR 2032) (included).
It is time to change the battery when the red LED on the transmitter does
not turn on when either button is pressed.
4. BATTERY
If, within one year from date of purchase, this product should become defective
(except battery), due to faulty workmanship or materials, it will be repaired or
replaced, without charge. Proof of purchase and a Return Authorization are required.
6. WARRANTY
5. FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
7. CUSTOMER SERVICE
Mounting
Bracket
CUSTOMER SERVICE
17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3
Email:[email protected]
http://www.skylinkhome.com
P/N. 101Z842-001
Patent Pending
©2010 SKYLINK GROUP
Smart Button TM GB-318 can learn up to 10 remote controls.
To program the transmitter to the receiver, follow the instructions below:
1. Press the learn button on the side of the Smart Button TM GB-318.
2. Once the learn button is pressed, the LED will
flash quickly. Release the learn button.
3. Within 30 seconds, press any one of the 3 buttons
on the transmitter that you want to program to the
receiver.
4. Once the remote control is programmed, the LED
will flash slowly, in the same way as it flashes
in standby mode.
5. You may now operate the garage door opener
with this new remote control.
6. To program this transmitter to control another
receiver, repeat process (1) to (4) to program
another button on the remote control.
Visor Clip
You need to do the programming in order to add the transmitter to a
Skylink
® Garage Door Opener.
Skylink ® Garage Door Opener can learn up to 16 remote controls.
To program the transmitter to the Garage Door Receiver, follow the
instructions below:
1. Press the LEARN/SET button once on the garage door opener.
2. Once the LEARN/SET buttton is pressed, the LEARN LED will flash.
You may release the LEARN/SET button.
3. Within 30 seconds, press any one of the 3 buttons on the transmitter
that you want to program to the receiver.
4. Once the transmitter is programmed, the LEARN LED will turn off.
5. You may now operate the garage door opener with this new transmitter.
6. To program a transmitter to control another garage door opener,
repeat process (1) to (4) to program another button on the transmitter.
2b. PROGRAM A TRANSMITTER TO THE SKYLINK ® GARAGE DOOR
OPENER - EQ SERIES
To program the transmitter to the Skylink ® IQ series Garage Door Opener,
please follow the user’s instruction from the Garage Door Opener.
3. TROUBLE SHOOTING
Q: What can I do if the door opener does not react after I press the button on
the transmitter ?
A: - Ensure when the button on the transmitter is pressed, the red light on the
transmitter comes on. Otherwise, check if the battery is inserted properly.
- Make sure the correct button on the transmitter is pressed.
- Ensure the wires that were previously connected to the wall mounted
door control are not loose.
- Ensure the transmitter has been programmed to the receiver. Refer
to section 2 for how to program a transmitter to the receiver.
2c. PROGRAM A TRANSMITTER TO THE SKYLINK ® GARAGE DOOR
OPENER - IQ SERIES
Learn Button
Double
Sided Tape
There are three buttons on transmitter G6T3, each button can be
programed to control Skylink garage door receiver Smart Button
TM GB-318
or GB-318-3 or Skylink garage door opener directly.
Follow one or more instructions below in Section 2 to program transmitter
G6T3 to the receiver or receivers you want to control.
Learn
Button
Smart Button TM
GB-318
LED
Antenna
If you would like to
- find out the up-to-date specifications
- know more about features and applications
- download documents, i.e. user’s instructions
- order Skylink products
or if you have difficulty getting products to work, please:
1. visit our FAQ section at www.skylinkhome.com, or
2. email us at [email protected], or
3. call our toll free at 1-800-304-1187 from Monday to Friday, 9 am to 5 pm EST.
Fax (800) 286-1320
