Sennheiser 2690443 - Manual

Cat. No. 005172
MD 46
Microphones | Dynamic Microphone
General Description
The MD 46 is a high-quality reporter’s microphone with cardioid pick-up
pattern. It has been specially optimised for rough use in live reporting
and broadcasting environments. The MD 46 is a very ‘good-natured’ micro-
phone whose design avoids wind and handling noise problems. Colour:
black.
Features
j Excellent speech clarity due to optimised frequency response
j Rugged and easy-to-handle microphone body
j Good sound quality
j Excellent suppression of handling noise
j Two-ply sound inlet basket provides increased protection
from wind and pop noise
j Delivery includes: 1 MD 46
Recommended Accessories
j MZW 4032 windshield, anthracite Cat. No. 002978
j MZW 1032-PRO velourised windshield, black Cat. No. 003746
j MZQ 800 microphone clamp Cat. No. 004711
Technical Data
Pick-up pattern ..................................................................... cardioid
Frequency response ................................................. 40 – 18,000 Hz
Sensitivity (free field, no load, 1 kHz).......... 2.0 mV/Pa ± 2.5 dB
Nominal impedance (1 kHz)................................................... 350
Ω
Min. terminating impedance ..................................................... 1 k Ω
Connector ............................................................................ 3-pin XLR
Dimensions ................................................................ Ø 49 x 250 mm
Weight ...........................................................................approx. 360 g
Profile
Cardioid reporter’s microphone, very insensitive to wind and
pop noise, max. front-to-back rejection at 1 kHz and 180°:
20 dB, frequency response 40 Hz to 18,000 Hz, sensitivity
(free field, no load) 2.0 mV/Pa ± 2.5 dB at 1 kHz, nominal
impedance 350
Ω at 1 kHz, min. terminating impedance
1,000 Ω, XLR-3 connector, dimensions Ø 49 x 250 mm, weight
approx. 360 g.
