Sub-Zero Drawer Microwave User Manual
Page 8
8
W O L F
D R AW E R M I C R OWAV E
3 0 " ( 7 6 2 )
D R A W E R
M I C R OWAV E
27
3
/
16
"
(691)
OPENING
HEIGHT
28
1
/
2
"
min
(724)
FLUSH
INSET
HEIGHT
28
1
/
2
"
(724)
E SERIES OVEN
OPENING WIDTH
36"
rec (914)
33"
min (838)
CABINET WIDTH
25"
min (635)
CABINET DEPTH
30
3
/
8
"
min (772)
FLUSH INSET WIDTH
28
1
/
2
"
(724)
DRAWER MICROWAVE
OPENING WIDTH
SIDE VIEW
NOTE: Refer to the 30" (762) E Series built-in oven specifications for electrical location.
*Platform must be able to support 250 lbs (113 kg).
E
19"
(483)
TO FLOOR
(typical)
7
/
8
"
(22) TOP CLEAT
5
/
16
"
(8) PLATFORM*
11
/
16
"
(17) PLATFORM
TOP VIEW
SIDE CLEATS
24
3
/
4
"
min
(629)
FLUSH
INSET
DEPTH
1
1
/
4
"
(32)
FOR DRAWER
MICROWAVE
1"
(25) FOR
E SERIES OVEN
14
3
/
4
"
(375)
OPENING
HEIGHT
15
15
/
16
"
(405)
FLUSH INSET
HEIGHT
1"
(25)
SIDE CLEATS
1"
(25)
SIDE CLEATS
The drawer microwave
can also be installed
using an electrical
outlet in an adjacent
cabinet within the area
where the provided
electrical cord can
reach. Power cord
access hole in cabinet
should be a minimum
1
1
/
2
" (38) diameter
hole and deburred of
all sharp edges.
IMPORTANT NOTE:
Always allow sufficient
power cord length to
the electrical outlet to
prevent tension.
Always check electrical
codes for requirements.
I N S T A L L A T I O N S P E C I F I C A T I O N S
Installation below a
Wolf E Series Built-In Oven
