airClient™ Nexus User Guide
Ethernet Traffic Statistics
Transmitted error
No of packets discarded because of format error
Received Bytes
Total No of packets received through the particular
interface
Received Unicast packets
Total No of packets received with a specified destination.
Received Multicast Packets
Total No of packets received with a specified destination.
Received Discards
No of packets discarded due to resource limitation
Received Errors
No of packets discarded because of form at error
The wireless statistics is also available from the ‘Radio Configuration’ Main Page.
Figure 6-2 Wireless Statistics from Radio Main Page
Table 6-2 Wireless Traffic Statistics
Wireless Traffic Statistics
Transmit Success Rate
No of successfully transmitted unicast and multicast
MPDU’s.
Transmit Multiple retry
No of unicast MPDU’s successfully transmitted after two or
more retries.
Transmit Retry rate
No of unicast MPDU’s successfully transmitted after one
retry.
Transmitted Failure count
No of unicast MPDU’s for which the maximum number of
retries were exceeded.
Received Success Rate
No of successfully received unicast MPDU’s
Received Duplicate Rate
No of successfully received unicast MPDU’s that were a
duplicate of earlier frames.
