COMMUNICATION SETUP TABLE
OFF ID not displayed
CAM ID
ON Camera names are displayed
OFF Communication ID display off.
DISP CAM ID
ON Communication ID display on.
BAUD RATE 2400 ~ 57600
Baud-rate set
(factory default : 2400).
UART MODE
8-E-1 / 8-0-1 /
8-N-1 Parity bits selectable.
(factory default : 8-N-1)
DISABLE
Do not send a command
back to the control & device.
RET PKT
ENABLE
Returning the data when
com-munication.(Caution
:
Activate this function to use
D&N.)
* Protocol: Pelco-D
IMAGE SETUP TABLE
OFF Freeze image : OFF.
FREEZE
ON Freeze image : ON
OFF Horizontal reverse : OFF
H-REV
ON Horizontal reverse : ON
OFF Vertical reverse : OFF
V-REV
ON Vertical reverse : ON.
OFF Sharpness control is disabled.
SHARPNESS
ON The Sharpness can be adjusted.
COLOR GAIN
The Color level can be
adjusted
(0~100)
SPECIFICATION
Model HT65010XS, HT65010XW
Camera Type
100X Day & Night Auto Focus Zoom
Dome Camera
Image Sensor 1/4" COLOR SONY SUPER HAD CCD
Effective Pixel 768(H) x 494(V)
TV Type NTSC
Scanning System 2 : 1 Interlace
Sync. System Internal / Line-Lock
Scan. Freq.(HORI)
INT: 15.734KHz
L/L: 15.750KHz
Scan. Freq.(VERT)
INT: 59.94Hz
L/L: 60.00Hz
Resolution 560 lines resolution
Video Output
1.0 Vp-p(Sync. Negative) with
75 Termination
S/N Ratio More than 50dB(Weight on)
Min. Illumination 0.02 Lux(F1.8) / 50IRE
Gamma γ = 0.45
Shutter Speed
Auto(x128 ~ 1/60 ~ 1/120,000sec)
Sense-up and Sense-up limit is selectable,
Flickerless
White Balance ATW / AWC / Manual(1,800 ~ 10,500°K)
SSNR LOW / MIDDLE / HIGH / OFF
Motion Detection
ON / OFF
(4 programmable zone per screen)
Privacy Function
ON / OFF
(32 zones, It consists of 8 group 4
programmable, zone per screen)
Flip
Vertical, Horizontal, Vertical-Horizontal,
OFF
Preset 8 position
OSD Yes
Zoom Optical zoom 10X, Digital zoom 10X
Focal Length f = 3.8 ~ 38(F 1.8)
Angle of View 51.2°(Wide End), 5.58°(Tele End)
Min. Working
Distance
1M
Communication RS-485
Power Supply 24 Volts AC, 12 Volts DC - Dual Voltage
Current
Consumption
Max. 500mA
Operating Temp. -14 °F to 120 °F
Preservation Temp. -4 °F to 140 °F
Dimension Ø150 x 99.1(H)mm
Weight 1.9 Ibs.
※AII specification is subject to change without notice to
improve the quality
3B05754A
HT65010XS, HT65010XW
