Function:
Page
I Remove the front fascia
5-7
II Remove shroud
8
III Stock Headlamps Removal
9
IV Ballast Install
10-12
V Install HID harness
13-16
VI Headlamp alignment
17
Part Number
Descriptions
Qty
00-9011-C11360*
SCREW, BUTTON HD SOCKET CAP SCREW, 18-8 SS, 10-32X1.25"
5
00-9003-C11359*
LOCKNUT, NYLON 18-8 SS, 10-32
5
06-1202-C11361A
SPACER, BALLAST 1/2" PLASTIC
2
06-1202-C11362A
SPACER, BALLAST .75" PLASTIC
3
06-1202-C11319A
HARNESS, HID 2005 MUISTANG
1
06-1202-C09903A
HEADLIGHT, BI-FUNCTION HID 5 3/4" RH KIT
1
06-1202-C09904A
HEADLIGHT, BI-FUNCTION HID 5 3/4" LH KIT
1
00-9001-C07636*
CAPSCRW BUT HD M6x1x16mm SS
1
069-700
4” Zip tie
10
069-310
SCREW PAN HD PHIL SELF DRIL 410 SS #8-18x1/2"
2
00-1202-C11457*
COVER, HID BALLAST FOR 05 MUSTANG
2
Obtain the following tools
• ¼” drive ratchet
• ¼” drive 5.5 mm shallow socket
• ¼” drive 8 mm socket
• ¼” drive 10 mm deep socket
• ¼” drive 10 mm shallow socket
• ¼” drive 10 mm shallow wobbly socket
• ¼” drive 1/8” Alan tool
• ¼” drive 3/8” deep socket
• ¼” drive 8” extension
• ¼” drive Short Phillips #2 bit
• Panel puller
• Drill
• Drill bit ¼”
• Drill bit 1/8”
• Panel puller
• Phillips head screw driver 10” long shaft
