Speco Technologies Day-Night All in one color camera 550TVL - Manual (Page 2)

SPECIFICATIONS
Model No. VL12
Image Pick-up Device IT Chip
Effective Picture Elements 768*492
Synchronization Internal
Horizontal Resolution 550 TV Lines
S/N Ratio 50 dB
Minimum Illumination 0 Lux (IR ON)
Auto Electronic Shutter Auto. 1/50 (60) ~ 1/100,000 Sec.
Gamma Characteristic 0.45
Gain Control Automatic Gain Control
White Balance Automatic White Balance (2500K~9500K)
Backlight Compensation Automatic Backlight Compensation
Lens Furnished 4.3mm Fixed Lens Built in
Infrared Luminary 24 Units of 850nm IR LED
IR Project Distance 65 Feet
Video Output 1 Vp-p / 75 Ohms. BNC Connector.
Power Supply DC 12V ± 10 %
Power Consumption Max. 90mA (IR Off); Max. 240mA (IR On)
Operating Temp. +4°F to 140° F
Protection Ratings IP66
Specifications are subject to change without prior notice.
200 New Highway
Amityville, NY 11701
1 800 645 5516
www.specotech.com
