P/N 211540C 12/02 12
Item Qty. Part No. Description
1 4 202341 “L” Bracket
2 2 200837 Spacer, Plastic
3 6 201107 Bolt, Hex Head, 1/4-20 x 1/2 Long
4 6 203326 Washer, Lock, 1/4
5 6 203228 Nut, 1/4-20
6 8 203100 Hex Flange Nut 5/16-18
7 4 203104 Bolt, Hex Flange, 5/16-18 x 2 Long
8 2 900964 Bracket, Backboard Support
9 2 206360 Bolt, Hex Head, 3/8-16 x 2.625 Long
10 2 200874 Spacer, Steel .402 I.D. x .50 O.D. x 1.5 Long
11 2 201124 Nut, 3/8-16
12 1 Rim
13 12* 200120 Clip, Net Holder, (Red)
12* 200121 Clip, Net Holder, (Black)
14 1 204281 Net
15 4 205528 Bolt, Hex Flange, 5/16-18 x 1 Long
16 8 203309 Washer, Flat
Item #13 (12*)
HARDWARE IDENTIFIER
PARTS LIST - See Hardware Identifier
* You May Have Extra Parts With This Model.
Item #3 (6)
Item #5 (6) Item #6 (8)
Item #11 (2)
Item #15 (4)
Item #16 (8)
Item #4 (6)
Item #10 (2)
Item #7 (4)
Item #9 (2)
